Garmin GPSMAP 16X3 User Manual

POWER Power and NMEA
®
0183 network
NETWORK Garmin Marine Network
J1939 J1939 engine network
Ground screw
CVBS IN Composite video in
SONAR 12-pin transducer (Not available on all models)
USB Micro-USB for compatible Garmin card reader
NMEA 2000 NMEA 2000
®
network
2 microSD
®
memory card slots, 32GB max.
GPSMAP 12x3 and GPSMAP 16x3 Connector View
POWER Power and NMEA 0183 network
SONAR 12-pin transducer (Not available on all models)
HDMI HDMI
®
video out
CVBS IN Composite video in
USB Micro-USB for compatible Garmin card reader
Ground screw
NETWORK Garmin Marine Network
NMEA 2000 NMEA 2000 network
J1939 Engine or J1939 network
2 microSD memory card slots, 32GB max.
3

Garmin GPSMAP 16X3 Specifications

General

Brand	Garmin
Model	GPSMAP 16X3
Category	Monitor
Language	English
