Garmin POWERSWITCH User Manual

Customizing a Button
1 From the Garmin PowerSwitch app screen, select Edit.
The app enters editing mode.
2 Select on the button you want to customize.
3 Select an option:
• To change the name of the button, select the Button Label field, and enter a name.
• To add an icon to the button, select the Icon field, and select an icon.
• To change the button color, select a color.
• To change the button mode, select a button mode.
• To adjust the intensity of the switch, use the slider.
• To set the button to activate with a control input, select a control input.
4 Select .
5 Select Done.
Assigning a Switch to a Control Input
Before you can use control input functions, you must connect a control input to your Garmin PowerSwitch
device (Connecting a Control Input, page 6).
You can assign one or more switches to turn on when the Garmin PowerSwitch device receives a signal from a
control input.
1 Select Settings.
2 Select your Garmin PowerSwitch device.
3 Select a control input.
4 Select one or more switches.
Adding a Custom Layout
You can add a custom layout tab to the Garmin PowerSwitch app. Buttons added to a custom layout can
control multiple switches at the same time.
1 From the Garmin PowerSwitch app, select Edit.
The device enters editing mode.
2 Select .
10 Garmin PowerSwitch App

Garmin POWERSWITCH Specifications

General

Output power (max)	100 W
Current loads per port (max)	30 A
AC outlets quantity	- AC outlet(s)
Grounding	Yes
Wire length	- mm
Product color	Black
International Protection (IP) code	IPX7

Weight and Dimensions

Depth	75 mm
Width	125 mm
Height	30 mm
Weight	283 g
