Normal Handset
Q’ty : 3
--Note--
Please use normal Handset for EMC TEST.
VHF300 BASE
Q’ty : 3
Handset with Audio input/output terminals
Q’ty : 3
--Note--
Please do not use the Handset which this arrangement was given for EMC TEST.
*22 ohm dummy load is installed instead of speaker.
*Speaker is not active.
*Microphone is not active.
Speaker with Audio output terminals / White resin material
Q’ty : 3
--Note--
Please do not use the Handset which this arrangement was given for EMC TEST.
*4ohm dummy load is installed.
*Speaker will active when un-pluged.
Normal Speaker / White resin material
Q’ty : 3
--Note--
Please use the normal Speaker for EMC TEST.
Items listed below were sent for testing.
JIGfor AFIN/OUT
