Preparation
RearFront
Control panel
Remote signal receptor
Handle
(both sides)
Horizontal louver control
lever(adjust manually)
NOTE: PHA cannot be
adjusted.
NOTE: PHA cannot be
adjusted.
Vertical louver control
lever(adjust manually)
Panel
Caster
Bottom tray
drain outlet
Air filter
(behind the grille)
Upper air intake
Air outlet
Lower air intake
Drain outlet
2
