1. Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
CODE PART QTY PALERMO
HOOD
A1
Hood (Pre-Assembled to Body)
1
A2 Hood Handle 1
A3 Warming Rack 1
BODY
B1 Barbecue Body 1
B2 Burner 4
B3 Control Panel 1
B4 Knob 4
B5 Hose/Regulator Assembly 1
B6 Flame Tamer 2
B7 Cooking Grill 1
B8 Cooking Plate 1
B9 Ignition Pushbutton 1
B10 Drip Tray Left Bracket 1
B11 Drip Tray Right Bracket 1
B12 Drip Tray 1
B13 Cylinder Hook 1
TROLLEY
C1 Side Shelf 2
C2 Left Front Leg 1
C3 Left Rear Leg 1
C4 Right Front Leg 1
C5 Right Rear Leg 1
C6 Screen 1
C7 Leg Support 1
C8 Cylinder Retainer 1
C9 Wheel 2
C10 Axle 1
C11 Wire Base 1
HARDWARE
D1 ST4.0x10 Screw 4
D2 M5x10 Bolt 2
D3 M5 Nut 2
D4 M6x15 Bolt 8
D5 M6x65 Bolt 8
D6 M6x70 Bolt 4
D7 Ø6 Washer 4
D8 M6 Nut 4
D9 Locknut 2
Pre-Assembled Component
Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased
