3. Hardware Reference Diagram
Specifications subject to change without prior notice.
Code Description Illustration
D1 ST4.0x10
Screw
D2 M5x10
Bolt
D3 M5 Nut
D4 M6x15
Bolt
D5 M6x65
Bolt
Code Description Illustration
D6 M6x70
Bolt
D7 Ø6 Washer
D8 M6 Nut
D9 Locknut
