GASTRON GIR-3000 User Manual

www.gastron.com
06
_
07
3. Specications
3.1. Basic Specifications
3.2. Mechanical Specifications
ITEMS SPECIFICATION
Measuring Type Diffusion type
Measuring Value Display Local Digital LCD or OLED Display
Measuring Method Non-Dispersive Infrared(NDIR)
Detectible Gas
Combustible Gas
Carbon dioxide (CO2)
Carbon monoxide(CO)
Measuring Range
Combustible:
0~9,999ppm / 0~100% LEL /
0~100% VOL
CO₂: 1.0% ~ 100% VOL
CO: 5% ~ 100% VOL
Accuracy ≤ ±3% / Full Range
Zero Drift ≤2% / Full Range
Response Time 90% of full scale in less than 10 sec
Approvals Classification
KCs: Ex d llC T6,T4, IP65
ATEX/IECEX: II 2 G Ex d IIC Gb T4,T6
SIL2, MED, ABS, DNV
Basic Interface Analog 4-20mA current interface
HART Interface HART REV7(Option)
Option
HART Board
MODBUS RS485 Board
GTL-100 warning light
Rain Cover
Warranty
Body (Transmitter) 2Year
Sensor 1Year
ITEMS SPECIFICATION
Explosion Proof type Pressure-resistant, explosion-proof enclosure
Dimension 156(W) × 322(H) × 110(D) mm
Weight including Sensor App. 3kg
Mounting type Wall mount
Mounting Holes Ø 7 ±0.1
Cable inlet 3/4" PF ( 1/2"or 3/4" NPT )
Body material
Body (Transmitter)
aluminum alloy
Sensor Stainless Steel (STS316)
