OPERATING INSTRUCTIONS
MEASUREMENT RANGE AND ON/OFF
BELOW DIAGRAM SHOWS THE USER INTERFACE ELEMENTS FOR CHANGING
THE MEASUREMENT RANGE AND SWITCHING THE DEVICE ON/OFF.
CURRENT MEASUREMENT
RANGE:
Range of frequencies within which
the belt resonance is expected.
Frequencies outside this range
will not be reported.
RANGES:
■
Low = 10-50 Hz
■
Standard = 50-500 Hz
■
High = 500-5000 Hz
■
Default = “Standard”
POWER BUTTON:
To switch on, press once.
To switch off, press and hold
for 2 seconds.
If inactive for 5 minutes, the device
will switch off automatically.
LOW BATTERY:
A low battery icon will appear when ~1
hour of constant usage remains.
RANGE BUTTON:
Press to cycle through 3 different ranges
(Low, Standard, High).
350C SONIC TENSION METER
GATES
5
GATES.COM
OPERATING INSTRUCTIONS
