Gates MobileCrimp 4-20 - Pump Specifications; Shop Air Pump; Hand Pump; 1;4 HP 12 Volt DC Pump

Carefully read and understand the following warnings before operating this crimper.
WARNING!
An incorrect hose assembly can rupture or blow apart in use, resulting in serious injury, death
or property damage. REMEMBER: Others depend on you to make correct assemblies.
FOR SAFETY
’ S SAKE
USE THIS MACHINE ONLY IF YOU:
1. Receive hands-on TRAINING with the MobileCrimp
®
4-20 and Gates assemblies.
2. Follow current GATES OPERATING MANUAL AND CRIMP DATA for the MobileCrimp 4-20.
3. Use only NEW (UNUSED) GATES hose and fittings.
4. Wear SAFETY GLASSES.
5. KEEP HANDS CLEAR OF MOVING PARTS. Support hose with one hand while activating
pump with other hand.
6. DO NOT operate pump UNLESS cylinder is locked in crimp position.
7. To avoid risk of injury, DO NOT use crimper UNLESS CONTROLLER BASE PLATE is in place.
8. DO NOT operate crimper in horizontal position.
Shop Air Pump
Prod. No.: 7481-0002, Part No.: 77820
Weight: 10 lbs.
1/4 H.P. 12 Volt DC Pump
Prod. No.: 7481-0037, Part No.: 77439
Weight: 20.5 lbs.
1/2 H.P. 115 Volt AC Pump
Prod. No.: 7481-0034, Part No.: 77441
Weight: 32 lbs.
Hand Pump
Prod. No.: 7481-0006, Part No.: 77821
Weight: 25.6 lbs.
1/4 H.P. 115 Volt AC Pump
Prod. No.: 7481-0033, Part No.: 77440
Weight: 20 lbs.
1-1/2 H.P. 115 Volt AC Pump
Prod. No.: 7481-0035, Part No.: 77442
Weight: 108 lbs.
Positive Stop Control
Prod. No.: 7480-0051, Part No.: 77421
Dimensions: 12 1/4" wide x 6 1/4"deep x 19 1/2" high
Weight: 57 lbs. (with stand)
Digital Dial Control
Pump Specifications
All pumps maximum rated working pressure: 10,000 psi
®
