3
Left side
www.gateway.com
Left side
Component Icon Description
Microphone jack Plug a microphone into this jack.
Line in jack Connect an external audio input source (such as a stereo) to this
jack so that you can record sound on your notebook or play sound
through the notebook speakers.
Headphone jack Plug amplified speakers or headphones into this jack. The built-in
speakers are turned off when speakers or headphones are
plugged into this jack.
The headphone jack on the port replicator is turned off when
headphones are plugged into this jack.
IEEE 1394 port Plug an IEEE 1394 (also known as Firewire
®
or i.Link
®
) device
(such as a digital camcorder) into this 4-pin IEEE 1394 port.
USB ports Plug USB (Universal Serial Bus) devices (such as a USB
Iomegaâ„¢ Zipâ„¢ drive, printer, scanner, camera, keyboard, or
mouse) into these ports.
PC Card
eject
buttons
PC Card
slots
Microphone jack
Headphone jack
Line in jack
IEEE 1394 port
USB ports
