13
Self-timer/ button Activates the self-timer. For additional information, see “Using
the self-timer” on page 35.
OSD active: Moves down through menu options.
Digital Zoom/OK button Activates digital zoom. For additional information, see “Using
the digital zoom” on page 34.
OSD active: Saves menu changes.
Delete button Deletes any images that you do not want to keep.
AV out connector Plug the AV cable in here to send still images or video to an
external device, such as a TV or VCR.
USB connector Plug the USB cable in here to transfer still images or video
to your computer.
Power connector Plug the optional AC power adapter in here. The power
adapter does not charge batteries.
Wrist strap eyelet Attach the wrist strap for your camcorder here.
Tripod socket (bottom) Attach a tripod here to stabilize your camcorder during
filming.
Item Description
09449.book Page 13 Tuesday, September 16, 2003 5:04 PM
