EXPLODED VIEW PARTS LIST
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Part No.
3091TKL027A
6304FLP003A
3809TKL019A
3043TKK078B
4951TKS034F
6633TZA004E
4951TKK065A
6871TMT246A
6631T11012K
4951TKK064A
6871TST239A
332-105F
332-095E
6634TBZ006M
6866TD9001L
6866TDV004F
Description
CABINET ASSEMBLY, LG883D G/WAY 3090TKL026A
LCD(LIQUID CRYSTAL DISPLAY), LM181E04-B3 LG PHILPS TFT COLOR 18.1
BACK COVER ASSEMBLY, LG883D 3808TKL022A
TILT SWIVEL ASSY, LG883D
METAL ASSY, FRAME MAIN LG883D
INVERTER ASSY, SAMSUNG LG1805 LG883D
METAL ASSEMBLY, SHIELD INVERTER
PWB(PCB) ASSEMBLY,MAIN, LG883D XAGC G/WAY MAIN TOTAL
CONNECTOR ASSEMBLY, 31P H-H 95MM UL20276 UNIXTAR LG883D
METAL ASSEMBLY, REAR LG883D
PWB(PCB) ASSEMBLY,SUB, LG883D XAGC G/WAY CONTROL TOTAL
SCREW, PVS+4*10(MSWR/FZMW)
SCREW, PZP+3*16(MSWR/FZMY)
ADAPTER, AC-DC, PSCV700101A SAMSUNG 12V 5.8A FOR LG883D(G/W)
CABLE,D-SUB, UL 2990-9C(7.5) DT 1870MM COOL GRAY 3C LB680A DM
CABLE, DVI, UL20276 DT 2000MM PEARL WH LG562F DM
