Gateway M675 Replacement Guide

5
www.gateway.com
Installing the keyboard
To install the keyboard:
1 Place the new keyboard keys-up on your notebook with the space bar
towards you. Be careful not to damage the LCD panel.
2 Verify the black plastic hinge on the system board keyboard connector is
in the raised position.
3 Insert the end of the keyboard cable between the black plastic hinge and
the white connector.
4 Press the black plastic hinge onto the keyboard cable.
Important The plug is correctly oriented if the cable is not twisted.

Gateway M675 Specifications

General

Processor	Intel Core 2 Duo
Screen Size	15.4 inches
Display Size	15.4 inches
CPU	Intel Core 2 Duo T7200
Memory	1GB DDR2 SDRAM (expandable to 4GB)
Display	15.4" WXGA
Operating System	Windows XP
Chipset	Intel 945PM
Processor Speed	2.0 GHz
Display Resolution	1280 x 800 (WXGA)
Optical Drive	DVD-RW
Operating System Version	Windows XP Professional
Dimensions	14.1 x 10.4 x 1.4 inches
Networking	10/100 Ethernet, 802.11a/b/g Wi-Fi
