GBC 620os Operation Manual
© 2007 General Binding Corporation Page 17
LOADING FILM & THREADING FILM
Figure 13
Figure 14
STEP 12:
• The Burst Roller can be adjusted up or down
determining weather more or less pressure is
needed for “Bursting”. Start by lowering the
roller by using the Burst Roller Knob until there
is about ½ to 1 inch of roll contact. (Figure 13).
• If the images are not separating, lower the Burst
Roller a little until consistent separation is
achieved.
STEP 13:
• Adjust the Paper Guides on the Rear Table so
that the separated sheets fall onto the Rear Table
and stay in a pile.
• The Angle of the Rear Table can be adjusted by
pushing in the pins and raising or lowering the
leg.
