GBC Fusion 5000L Start Here

Electrical 220-240V AC / 50Hz-60Hz /
6.5A / 1520W
Machine Dimensions 570x193x132mm
Machine Weight 4.6kg
Maximum Pouch Width A4: 241mm
A3: 303mm
Maximum Pouch
Thickness
2x250micron (total 500)
Maximum Thru-put
Thickness
1.0mm
Warm-Up Time Approximately 1 minute
Speed Variable (max.: 1000mm/min.)
technical specifications
service
Do not attempt to service or repair the pouch laminator yourself. Unplug the unit and contact an
authorised GBC service representative for any required repairs.
GB
FUSION
™
5000L A3 LAMINATORS 5
points to note
• Use this unit only for its intended use of laminating documents
• Only use 75mic, 125mic, 175mic or 250mic pouches with this laminator
• Do not laminate an empty pouch
• The unit must be connect to a supply voltage corresponding to the electrical rating shown
on the unit
• The socket-outlet shall be installed near the equipment and shall be easily accessible.
• Ensure the machine is clear of pouches prior to starting the next pouch
• Clear the lamination rollers on a regular basis
• Maximum A3 document pouch 426x303mm on GBC Fusion 5000L A3 Laminator
• Active anti jam feature may not detect issue on smaller items
• Failure to comply will result in damage and invalidate guarantee
m
m
m
m

GBC Fusion 5000L Specifications

General

Type	-
Format	A3
Warm-up time	1 min
Product color	Black
Laminating time	60 s
Preheating time	- min
Built-in display	Yes
Lamination speed	1000 mm/min
Country of origin	China
Lamination system	Pouch
Maximum pouch thickness	250 µm
Minimum pouch thickness	75 µm
Maximum lamination width	303 mm
Maximum document thickness	- mm

Weight and Dimensions

Package width	655 mm
Package height	235 mm
Package weight	5705 g
