GBC Fusion 5000L Start Here

loading the pouch
1 Take your item to be laminated and place into the laminating pouch. Ensuring it is rmly placed
along the sealed edge of the pouch. This is to help ensure that you get optimal quality output.
Before laminating important or unique documents, always run a test pouch through
the laminator using a similar type document.
SEALED EDGE
A3, A4, A5, etc. Irregular shaped item
SEALED EDGE
NOTE: Do not cut pouches prior to
lamination.
GB
FUSION
™
5000L A3 LAMINATORS 7

GBC Fusion 5000L Specifications

General

Type	-
Format	A3
Warm-up time	1 min
Product color	Black
Laminating time	60 s
Preheating time	- min
Built-in display	Yes
Lamination speed	1000 mm/min
Country of origin	China
Lamination system	Pouch
Maximum pouch thickness	250 µm
Minimum pouch thickness	75 µm
Maximum lamination width	303 mm
Maximum document thickness	- mm

Weight and Dimensions

Package width	655 mm
Package height	235 mm
Package weight	5705 g
