Freezer pans
Pull the drawer out to the stop
position, rotate all four swing
locks to the unlock position
and lift the front of the pan up
and out.
To replace make sure all four
swing locks are in the unlock
position, place the sides of
the drawer into the drawer
supports, making sure the
swing locks t on the drawer
slots and lock all four swing
locks by rotating them to the
lock position.
MAXIMUM STORAGE
CAPACITY
Refrigerator
slide-out shelf
20 Kg
Module
bin
7 Kg
Fixed
bin
4 Kg
Refrigerator
upper pan
20 Kg
Refrigerator
bottom pan
8 Kg
Big freezer
shelf
16 Kg
Small freezer
shelf
8 Kg
Freezer
shelf
3 Kg
Freezer
upper pan
9 Kg
Freezer
bottom pan
3 Kg
ESTIMATED SHELF STORAGE AREA
Capacity Storage Area
dm
2
22’ AND 23’ 176
Note: Values can change according to the model.
