GE Security FireShield FS502 - Setting Up IDC Event Codes; Ending Programming

Programming
3.16 FireShield Technical Reference Manual
Format: 2 digits (0 – 9 and A – F)
Default: See Appendix E “Default event codes.” These can be
changed if needed.
Note: If you are using Contact ID or the default 4/2 codes, you
can skip ahead to “End programming” now.
To change system event codes:
1. Press Reset or Signal Silence & Drill to scroll to the event
code that you want to change.
2. Press Reset to change the first digit of the code.
3. Press Panel Silence to save and advance to the next digit.
The trouble buzzer sounds a long beep as confirmation.
4. Press Reset to change the second digit.
5. Press Panel Silence to save.
6. Press Reset to advance to the next event code.
4. Set up or change IDC event codes
Description: Defines the 4/2 event codes (alarm, sup, trouble,
etc.) that are sent to the CMS for IDC events.
Format: 2 digits (0 – 9 and A – F)
Default: See Appendix E “Default event codes.” These can be
changed if needed.
To change IDC event codes:
1. Select an IDC for programming by pressing the Disable
button for that IDC.
2. Press Reset or Signal Silence & Drill to scroll to the event
code that you want to change.
3. Press Reset to change the first digit of the code.
4. Press Panel Silence to save and advance to the next digit.
The trouble buzzer sounds a long beep as confirmation.
5. Press Reset to change the second digit.
6. Press Panel Silence to save.
7. Repeat steps 1 through 6 for each IDC you want to
program.
8. Press Reset to advance to the next event code.
5. Set up or change the IDC zone restoration code
Description: Sets the 4/2 event code that is transmitted to the
CMS for an IDC restoral event.
Format: 1 digit (0 – 9 and A – F)
Default: See Appendix E “Default event codes.” This can be
changed if needed.
To change the IDC zone restoration code:
1. Press Reset to change the IDC zone restoration code.
2. Press Panel Silence to save and advance to the next
program option.
The trouble buzzer sounds a long beep as confirmation.
6. Set up or change the NAC trouble code
Description: Sets the 4/2 event code that is transmitted to the
CMS for a NAC trouble event.
Format: 2 digits (0 – 9 and A – F)
Default: See Appendix E “Default event codes.” This can be
changed if needed.
To change the NAC trouble code:
1. Select an NAC for programming by pressing the Disable
button for that NAC.
2. Press Reset to change the first digit of the code.
3. Press Panel Silence to save and advance to the next digit.
The trouble buzzer sounds a long beep as confirmation.
4. Press Reset to change the second digit.
5. Press Panel Silence to save.
6. Repeat steps 1 through 5 for each NAC you want to
program.
7. Press Reset to advance to the next program option.
7. Set up or change the NAC trouble restoration code
Description: Sets the 4/2 event code that is transmitted to the
CMS for a NAC restoral event.
Format: 1 digit (0 – 9 and A – F)
Default: See Appendix E “Default event codes.” This can be
changed if needed.
To change the NAC trouble restoration code:
1. Press Reset to change the NAC trouble restoration code.
2. Press Panel Silence to save and advance to the next
program option.
The trouble buzzer sounds a long beep as confirmation.
8. End programming
Programming is complete.
To end programming:
1. Press Panel Silence.
