FireShield Technical Reference Manual B.1
Appendix B
Programming templates
Panel programming worksheet
Project name _____________________________ Project address ___________________________________________________________
Programmed by __________________________ Date ____________ Tested by ____________________________ Date ____________
[1] Load defaults No (1) Yes (2)
[2] Find annunciators Peripherals installed
Peripherals found
[3] Auto NAC silence timer None (1) 20 minutes (2)
[4] Aux power reset No (1) Yes (2)
[5] Signal silence inhibit timer None (1) 1 minute (2)
[6] IDC zone types IDC1 IDC2 IDC3 IDC4 IDC5 IDC6 IDC7 IDC8 IDC9 IDC10
Alarm-unverified (1)
Alarm-verified (2)
Waterflow (retard) (3)
Waterflow (no retard) (4)
Waterflow (retard) /
supervisory(latching) (5)
Waterflow (no retard) /
supervisory(latching) (6)
Supervisory (latching) (7)
Monitor (8)
NAC Assignment IDC1 IDC2 IDC3 IDC4 IDC5 IDC6 IDC7 IDC8 IDC9 IDC10
NAC1
NAC2
NAC3
NAC4
[7] IDC class
Class B (1)
Class A (2)
[8] NAC classes NAC1 NAC2 NAC3 NAC4
Class B (1)
Class A (2)
[9] NAC outputs
Continuous (1)
Temporal (3-3-3) (2)
GENESIS synch/silence (3)
No (1) No (1) No (1) No (1)[10] NAC silenceable
Yes (2) Yes (2) Yes (2) Yes (2)
[ ] = Top row of LEDs binary number value
( ) = Bottom row of LEDs binary number value
= Factory default settings
Button definitions (programming mode)
Remote disconnect - Selects next option
Walk test - Selects previous option
Reset - Selects next setting
Signal Silence & Drill - Selects previous setting
Panel Silence - Saves program setting
Panel LEDs and binary number values
ALARM SUPTROUBLE POWER DISABLE
16 8 4 2 1
Binary values
SIGNAL
SILENCED
WALK
TEST
GND
FAULT
BATT
TROUBLE
ANNUN
TROUBLE
16 8 4 2 1
Binary values
