42
NX-8V2 Control
LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
105 27
Segment 2
1 = LED extinguish enable
2 = Require user code for bypassing zones
3 = Bypass sounder alert
4 = AC power/low battery sounder alert
5 = Enables bypass toggle
6 = Enables silent auto arm
7 = Enables auto instant
8 = Reserved
Segment 3
1 = Open/Close
2 = Bypass
3 = Restore
4 = Trouble
5 = Tamper
6 = Cancel
7 = Recent Closing
8 = Exit Error
Segment 4
1 =Late to Close / Early to Open
2-8 = Reserved
Segment 5 RESERVED
106 27 PARTITION 7 ENTRY/EXIT TIMERS
Segment 1: Entry Time 1 0 _
Segment 2: Exit Time 1 0 _
Segment 3: Entry Time 2 0 _
Segment 4: Exit Time 2 0 _
Segment 5 & 6 RESERVED
107 27 PARTITION 8 ACCOUNT CODE 10-10-10-10-10-10 _ _ _ _ _ _
108 27 PARTITION 8 FEATURE AND REPORTING SELECTION
Segment 1
1 = Quick Arm
2 = Re-Exit
3 = Auto Bypass
4 = Silent Panic
5 = Audible Panic
6 = Auxiliary 1
7 = Auxiliary 2
8 = Multi Keypress Tamper
Segment 2
1 = LED extinguish enable
2 = Require user code for bypassing zones
3 = Bypass sounder alert
4 = AC power/low battery sounder alert
5 = Enables bypass toggle
6 = Enables silent auto arm
7 = Enables auto instant
8 = Reserved
Segment 3
1 = Open/Close
2 = Bypass
3 = Restore
4 = Trouble
5 = Tamper
6 = Cancel
7 = Recent Closing
8 = Exit Error
Segment 4
1 =Late to Close / Early to Open
2-8 =Reserved
Segment 5 RESERVED
109 27 PARTITION 8 ENTRY/EXIT TIMERS
Segment 1: Entry Time 1 0 _
Segment 2: Exit Time 1 0 _
Segment 3: Entry Time 2 0 _
Segment 4: Exit Time 2 0 _
Segment 5 & 6 RESERVED
110 28 ZONE TYPE 1 ALARM EVENT CODE 8 _
111 28 ZONE TYPE 1 CHARACTERISTIC SELECT
Segment 1
1 = Fire (enable for fire zone)
2 = 24-Hour (enable for non-fire 24 hour)
3 = Keyswitch zone
4 = Follower (enable for burg zones that are
instant during non-entry times)
5 = Delay 1 zone (enable to follow Timer 1 Entry/Exit times)
6 = Delay 2 zone (enable to follow Timer 2 Entry / Exit times)
7 = Interior (Enable for auto bypass or stay arming)
8 = Local Only (enable if zone is not to be reported)
Segment 2
1 = Keypad audible on alarm.
2 = Yelping siren on alarm.
3 = Temporal siren on alarm.
4 = Chime.
5 = Bypassable.
6 = Group Shunt.
7 = Force armable.
8 = Entry Guard.
