GE Security NX-8V2 User Manual

NX-8V2-Control Panel
Installation Instructions
10
Specifications
Operating power 16.5 VAC 40 or 50 VA transformer
Auxiliary power
w/25 VA transformer
w/40 or 50 VA transformer
(MG Electronics part
number 22-156 for US or
22-156-CN for Canadian
installations)
12 VDC regulated 500 mA
12 VDC regulated 1 A
Loop resistance
Standard loop 300 ohms maximum
Fuse Type T 200 mA 250 VAC
Built in siren driver Two tone (temporal and yelp)
Loop response Selectable 50 mS or 500 mS
Operating temperature 32 to 120°F (0 to 49°C)
LED keypad
Current draw
Zones normal w/o sounder
Dimensions
130 mA max.
55 mA
6.4 x 4.0 x 1.1 in. (16.3 x 10.2 x 2.8 cm)
NX148E LCD keypad
Current draw
Without sounder
Dimensions
110 mA max.
75 mA
6.4 x 5.3 x 1.0 in. (16.3 x 13.5 x 2.5 cm)
Metal enclosure dimension 11.25 x 11.25 x 3.50 in. (28.58 x 28.58 x 8.90
cm)
Shipping weight 9 lb. (4.1 kg)
FCC This device complies with part 15 of the FCC rules. Operation is subject to the
following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Complies with Part 68 FCC Rules.
ACTA (FCC) ID: GCQUSA-33408-AL-E
IC: 1175A-NXV2
Technical support
888 GE Security (888.437.3287). Toll-free in the US, Puerto Rico, and Canada.
503.885.5700 outside the toll-free area or contact your local dealer.
www.gesecurity.com

GE Security NX-8V2 Specifications

General

Brand	GE Security
Model	NX-8V2
Category	Control Panel
Language	English
