PAGE 5: ACTUAL VALUES
PRE-TRIP DATA
ACTUAL VALUES page 5 header.
52
PRE-TRIP AVERAGE MOTOR
CURRENT = XXXXX AMPS
Average motor phase current prior to last relay trip.
53
PRE-TRIP U/B RATIO
(In/Ip) XXX PERCENT
Ratio of negative to positive sequence currents prior to last relay trip.
54
PRE-TRIP G/F CURRENT
G/F = XXX AMPS
Ground fault current prior to last relay trip.
55
PRE-TRIP MAX STATOR RTD
RTD # X = XXX C
Maximum stator RTD temperature prior to last relay trip.
56
END OF PAGE FIVE
ACTUAL VALUES
Last line of page 5.
