3 SETUP AND USE
g
GE Power Management
39
3$*( /,1( '(6&5,37,21
61
PAGE 6: ACTUAL VALUES
LEARNED PARAMETERS
ACTUAL VALUES page 6 header.
62
LEARNED Istart (AVG.OF 4
STARTS) = XXX AMPS
Learned average motor starting current over past 4 starts.
63
LEARNED Istart (last one)
= XXX AMPS
Learned motor starting current from last start.
64
LEARNED K FACTOR
K = XX.X
Learned value of negative sequence K factor.
65
LEARNED RUNNING COOL
TIME= XXX MIN.
Learned motor cooling time with motor running (see section 3.20).
66
LEARNED STOPPED COOL
TIME= XXX MIN.
Learned motor cooling time with motor stopped (see section 3.20).
67
LEARNED ACCEL. TIME
ACCEL. TIME = XX.X SEC.
Learned motor acceleration time.
68
LEARNED Start Capacity
required = XX PERCENT
Learned motor thermal capacity used during a start.
69
END OF PAGE SIX
ACTUAL VALUES
Last line of page 6.
* 169 Plus only
