3 SETUP AND USE
g
GE Power Management
40
To place the relay in ACTUAL VALUES mode, the ACTUAL VALUES key must be pressed. When this is done the
following flash message will appear for 2 seconds,
ACTUAL VALUES HAS SIX
PAGES OF DATA
The display will then show,
PAGE 1: ACTUAL VALUES
PHASE CURRENT DATA
which is the beginning of page 1.
If the relay is in SETPOINTS mode or ACTUAL VALUES mode and no key is pressed for more than four minutes the
display will change to, (factory default settings)
I1= XXX I2= XXX
I3= XXX (AMPS) ---
which is the third line in page 1 of ACTUAL VALUES mode. This default display line can be changed in page 5 of
SETPOINTS mode.
When in this mode the PAGE UP, PAGE DOWN, LINE UP, and LINE DOWN keys (see section 3.1) can be used to
examine all of the actual motor data outlined above.
