GE 169 - Page 50

3 SETUP AND USE
g
GE Power Management
44
3$*( ,1)250$7,21 /,1( 5$1*( 0$18$/ 5()
2
PAGE 2: SETPOINT VALUES
RTD SETPOINTS
2
# OF STATOR RTDS USED
# OF RTDs = X
0-6 (increments of 1) 3.16
2
RTD #1 ALARM LEVEL
= XXX DEGREES C
or
STATOR #1 ALARM LEVEL
= XXX DEGREES C
0-200 degrees C or OFF (increments of 1) 3.16
2
RTD #1 TRIP LEVEL
= XXX DEGREES C
or
STATOR #1 TRIP LEVEL
= XXX DEGREES C
0-200 degrees C or OFF (increments of 1) 3.16
2
RTD #2 ALARM LEVEL
= XXX DEGREES C
or
STATOR #2 ALARM LEVEL
= XXX DEGREES C
0-200 degrees C or OFF (increments of 1) 3.16
2
RTD #2 TRIP LEVEL
= XXX DEGREES C
or
STATOR #2 TRIP LEVEL
= XXX DEGREES C
0-200 degrees C or OFF (increments of 1) 3.16
2
RTD #3 ALARM LEVEL
= XXX DEGREES C
or
STATOR #3 ALARM LEVEL
= XXX DEGREES C
0-200 degrees C or OFF (increments of 1) 3.16
2
RTD #3 TRIP LEVEL
= XXX DEGREES C
or
STATOR #3 TRIP LEVEL
= XXX DEGREES C
0-200 degrees C or OFF (increments of 1) 3.16
