GE 169 - Page 54

3 SETUP AND USE
g
GE Power Management
48
3$*( ,1)250$7,21 /,1( 5$1*( 0$18$/ 5()
*3
TRIP TIME @ 3.50 X FLC
= XXXX SECONDS
1-2000 seconds (increments of 1) 3.18
*3
TRIP TIME @ 4.00 X FLC
= XXXX SECONDS
1-2000 seconds (increments of 1) 3.18
*3
TRIP TIME @ 4.50 X FLC
= XXXX SECONDS
1-2000 seconds (increments of 1) 3.18
*3
TRIP TIME @ 5.00 X FLC
= XXXX SECONDS
1-2000 seconds (increments of 1) 3.18
*3
TRIP TIME @ 5.50 X FLC
= XXXX SECONDS
1-2000 seconds (increments of 1) 3.18
*3
TRIP TIME @ 6.00 X FLC
= XXXX SECONDS
1-2000 seconds (increments of 1) 3.18
*3
TRIP TIME @ 6.50 X FLC
= XXXX SECONDS
1-2000 seconds (increments of 1) 3.18
*3
TRIP TIME @ 7.00 X FLC
= XXXX SECONDS
1-2000 seconds (increments of 1) 3.18
*3
TRIP TIME @ 7.50 X FLC
= XXXX SECONDS
1-2000 seconds (increments of 1) 3.18
*3
TRIP TIME @ 8.00 X FLC
= XXXX SECONDS
1-2000 seconds (increments of 1) 3.18
3
END OF PAGE THREE
SETPOINT VALUES
*
169 Plus only
