PAGE 4: SETPOINT VALUES
RELAY CONFIGURATION
This page assigns trip and alarm functions to specific output relays (i.e. TRIP, ALARM, AUX. 1, AUX. 2
on the 169 Plus, or TRIP and ALARM on the model 169). Each trip/alarm function is assigned
separately to the appropriate relay or to "NO" relay. If an alarm feature is assigned to no relay, it can still
become active (i.e. cause the appropriate alarm message to be displayed if setpoints are exceeded) but
no output relay activation will occur. Possible assignments and factory values are shown below.
Only
one TRIP may occur at any one time. TRIP functions must therefore be used to trip the motor.
Once one TRIP function is active, no other trip may occur.
4
Assign XXXXXXXXXXXXXXXX
to XXXXXXXXXXXX relay
For the model 169 Plus:
Feature Possible Assignments Factory Value
O/L TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
U/B TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
S/C TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
RAPID TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
STATOR RTD TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
RTD TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
G/F TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
ACCEL. TIME TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
PHASE REV. TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
STARTS/HOUR TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
SPEED SWITCH TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
DIFFERENTIAL TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
SINGLE PHASE TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
SPARE INPUT TRIP TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
START INHIBIT TRIP or AUX. 1 or TRIP & AUX.1 TRIP RELAY
O/L WARNING ALARM or AUX. 1 or AUX. 2 or NO ALARM RELAY
G/F ALARM ALARM or AUX. 1 or AUX. 2 or NO ALARM RELAY
U/B ALARM ALARM or AUX. 1 or AUX. 2 or NO ALARM RELAY
U/C ALARM ALARM or AUX. 1 or AUX. 2 or NO ALARM RELAY
STATOR RTD ALARM ALARM or AUX. 1 or AUX. 2 or NO AUX. 1 RELAY
RTD ALARM ALARM or AUX. 1 or AUX. 2 or NO AUX. 1 RELAY
NO SENSOR ALARM ALARM or AUX. 1 or AUX. 2 or NO AUX. 1 RELAY
SELF-TEST FAIL ALARM or AUX. 1 or AUX. 2 or NO AUX. 2 RELAY
SPARE INPUT ALARM ALARM or AUX. 1 or AUX. 2 or NO NO RELAY
For the model 169:
Feature Possible Assignments Factory Value
O/L TRIP (not shown) TRIP RELAY
U/B TRIP (not shown) TRIP RELAY
S/C TRIP (not shown) TRIP RELAY
RAPID TRIP (not shown) TRIP RELAY
STATOR RTD TRIP (not shown) TRIP RELAY
RTD TRIP (not shown) TRIP RELAY
G/F TRIP (not shown) TRIP RELAY
ACCEL. TIME TRIP (not shown) TRIP RELAY
PHASE REV. TRIP (not shown) TRIP RELAY
STARTS/HOUR TRIP (not shown) TRIP RELAY
SINGLE PHASE TRIP (not shown) TRIP RELAY
O/L WARNING ALARM or NO ALARM RELAY
G/F ALARM ALARM or NO ALARM RELAY
U/B ALARM ALARM or NO ALARM RELAY
U/C ALARM ALARM or NO ALARM RELAY
STATOR RTD ALARM ALARM or NO ALARM RELAY
RTD ALARM ALARM or NO ALARM RELAY
NO SENSOR ALARM ALARM or NO ALARM RELAY
SELF-TEST FAIL ALARM or NO ALARM RELAY
