3 SETUP AND USE
g
GE Power Management
53
3$*( '(6&5,37,21
5
Enable Single-shot
restart ? XXX
(model 169 Plus only) This setpoint is used to enable or defeat the single-shot restart feature described
in section 3.22.
YES - Single-shot restart enabled; NO - Single-shot restart disabled. Factory Value = NO
5
Enable start inhibit?
XXX
(model 169 Plus only) This setpoint is used to enable or defeat the Start Inhibit feature of the relay
described in section 3.20:
YES - Start Inhibit enabled; NO – Start Inhibit disabled
Note: This setpoint should not be changed until the 169 relay has obtained a reasonable value
for the "LEARNED Start Capacity required" (SETPOINTS mode, page 6).
Factory Value = NO
5
Enable special external
reset function? XXX
(model 169 Plus only) This setpoint is used to enable or defeat the special external reset feature
described in sections 2.13, 3.22.
YES - special external reset enabled; NO - special external reset disabled. Factory Value = NO
5
Enable phase reversal?
XXX
This code is used to defeat or enable the Phase Reversal Trip function.
YES - Phase Reversal Trip function enabled; NO - Phase Reversal Trip function disabled
Note: If only two phase CTs are used, as shown in Figure 2-6, this setpoint must be set to NO.
Factory Value = NO
