Installation Instructions
24
IMPORTANT NOTES
When removing freezer drawer:
• Read the instructions all the way through before
starting.
• Provide a non-scratching work surface for the
doors.
1
REMOVE THE BASKETS
A. Open the freezer drawer until it stops.
B. Pull the top basket out until it stops. Lift the
basket up on the front and out to remove.
C. The lower basket rests on a frame inside the
freezer drawer. Lift the front of the basket and
pull it forward. Release the pins from the slots
on the frame to remove the basket.
2
REMOVE THE DRAWER FRONT
A. Remove the screw on each side of the railing.
B. Lift up on both sides of the freezer drawer
handle to separate the drawer railings from
the rail assemblies.
C. Set the drawer front on a non-scratching
surface.
D. Push the rail assemblies back into locking
position.
REMOVING FREEZER DRAWER (on some models)
Screw
Drawer
Assembly
Rail
Assembly
To Next Page
