K0554 Revision A 3
Figure 1 ADTS Touch docking connector
The ADTS Touch is equipped with an On/Off switch (2) and USB connectors for connection
to a PC or mass storage device (3).
Figure 2 ADTS Touch On/Off switch and USB connectors
Connector (4) allows connection between the base unit and the ADTS Touch using a 5
metre or 18 metre umbilical cable.
Note: Only use cables that have been supplied by or purchased from GE.
