Introduction
This instruction describes the General Purpose I/O option OPCGPIO for use in the AF-600 FP and AF-650 GP series, expanding the number of input/output in the
frequency converter.
The OPCGPIO option includes 3 digital inputs, 2 analog inputs, 2 digital outputs and 1 analog output.
SW firmware version to be installed in the drive control card must be version 3.00 or later versions for AF-650 GP series, and version X.XX for AF-600 FP series.
Check par. ID-43 Software Version for firmware version.
1.1.2 Product Number: OPCGPIO
Illustration 1.1:
AF-650 GP and AF-600 FP OPCGPIO General Purpose I/O Option Module
