Short
-
Time
Delay
(
Optional
)
The
short
-
time
delay
adjust
-
ment
is
used
in
conjunction
with
the
short
-
time
pickup
setting
to
provide
a
further
refinement
of
coordination
between
circuit
breakers
.
It
establishes
the
time
interval
the
breaker
will
wait
before
responding
to
the
short
-
circuit
current
level
selected
on
the
short
-
time
trip
point
adjustment
.
SHORT
TIME
DELAY
I
2
T
OUT
DELAY
The
instantaneous
trip
point
determines
the
level
at
which
the
breaker
will
trip
without
intentional
time
delay
(
0.025
seconds
or
less
)
.
This
immediate
inter
-
ruption
occurs
only
as
a
result
of
a
severe
overcur
-
rent
condition
,
thereby
mini
-
mizing
damage
to
the
electri
-
cal
system
and
equipment
.
Adjustable
Instantaneous
Pickup
(
Standard
)
INSTANTANEOUS
PICKUP
INSTANTANEOUS
PICKUP
19
