Spare Parts ASTAT XL Service Manual
Connect the coloured firing looms to the numbered gates according to the diagrams below:
Models 0023~0076
7
6 5
4
7 6 5 4
SEMIKRON
I
N
FI
NE
O
N
03297.C
Models 0097~0145
5
4
7
6
4
5
6
7
SEMIKRON INFINEON
03298.C
Models 0170~0255
7 6 5 4
7 6 5 4
SEMIKRON INFINEON
03299.C
Models 0350~0425
14526.A
5
4 7
6
NOTE
Unless otherwise indicated, spare part kits contain only one of each item.
All images in this section are indicative.
