CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-91
2
" 6714 Subharmonic Stator Ground Stage 2 Pickup
Delay
0.1 to 600 s 0.1 F001 10
" 6715 Subharmonic CT Angle Compensation -30 to 30 degrees 0.1 F002 0
" 6718 Subharmonic Stator Ground OC Pickup 0.001 to 1 pu 0.001 F001 10
" 6719 Subharmonic Stator Ground OC Delay 0.1 to 600 s 0.01 F001 100
" 671A Subharmonic Stator Ground Volt Supv 0 to 0.1 pu 0.001 F001 0
" 671B Subharmonic Stator Ground Curr Supv 0 to 0.1 pu 0.001 F001 0
" 671C Subharmonic Stator Ground Block 0 to 4294967295 --- --- F300 0
" 671E Subharmonic Stator Ground Events 0 to 1 --- 1 F102 0 (Disabled)
" 671F Subharmonic Stator Ground Target 0 to 2 --- 1 F109 0 (Self-reset)
Stator Ground (Read/Write Grouped Setting)
G30, G60 6720 Stator Ground Function 0 to 1 --- 1 F102 0 (Disabled)
" 6721 Stator Ground Stage 1 Pickup 0 to 0.9 pu 0.001 F001 150
" 6722 Stator Ground Stage 1 Pickup Delay 0 to 600 s 0.01 F001 100
" 6723 Stator Ground Stage 1 Supv 0.001 to 0.1 pu 0.000
1
F001 57
" 6724 Stator Ground Stage 2 Pickup 0 to 0.9 pu 0.001 F001 150
" 6725 Stator Ground Stage 2 Pickup Delay 0 to 600 s 0.01 F001 0
" 6726 Stator Ground Stage 2 Supv 0.001 to 0.1 pu 0.000
1
F001 45
" 6727 Stator Ground Block 0 to 4294967295 --- 1 F300 0
" 6729 Stator Ground Target 0 to 2 --- 1 F109 0 (Self-reset)
" 672A Stator Ground Event 0 to 1 --- 1 F102 0 (Disabled)
" 672B Reserved (5 items) 0 to 65535 --- 1 F001 0
Split Phase Protection (Read/Write Grouped Setting)
G30, G60 6730 Split Phase Protection Function 0 to 1 --- 1 F102 0 (Disabled)
" 6731 Split Phase Protection Source 0 to 5 --- 1 F167 0 (SRC1)
" 6732 Split Phase Protection Load Source 0 to 5 --- 1 F167 0 (SRC1)
" 6733 Split Phase Protection Phase A Pickup 0.02 to 1.5 pu 0.001 F001 200
" 6734 Split Phase Protection Phase A Offset 0 to 1 pu 0.001 F001 0
" 6735 Split Phase Protection Phase A Slope 0 to 100 % 0.1 F001 0
" 6736 Split Phase Protection Phase B Pickup 0.02 to 1.5 pu 0.001 F001 200
" 6737 Split Phase Protection Phase B Offset 0 to 1 pu 0.001 F001 0
" 6738 Split Phase Protection Phase B Slope 0 to 100 % 0.1 F001 0
" 6739 Split Phase Protection Phase C Pickup 0.02 to 1.5 pu 0.001 F001 200
" 673A Split Phase Protection Phase C Offset 0 to 1 pu 0.001 F001 0
" 673B Split Phase Protection Phase C Slope 0 to 100 % 0.1 F001 0
" 673C Split Phase Protection Minimum Load 0 to 1 pu 0.01 F001 0
" 673D Split Phase Protection Mode 0 to 1 --- 1 F225 0 (Over)
" 673E Split Phase Protection Delay 0 to 65.535 s 0.001 F001 0
Bus Configuration (Read/Write Setting) (6 Modules)
B90 673E ...Repeated for Bus Zone 5
Split Phase Protection (Read/Write Grouped Setting)
G30, G60 673F Split Phase Protection Block 0 to 4294967295 --- 1 F300 0
" 6741 Split Phase Protection Target 0 to 2 --- 1 F109 0 (Self-Reset)
" 6742 Split Phase Protection Events 0 to 1 --- 1 F102 0 (Disabled)
" 6743 Reserved (6 items) 0 to 65535 --- 1 F001 0
Products Address Register name Range Units Step Format Default
