CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-175
2
" D34E IEC 61850 GGIO2.CF.SPCSO47.ctlModel
Value
0 to 2 --- 1 F001 1
" D34F IEC 61850 GGIO2.CF.SPCSO48.ctlModel
Value
0 to 2 --- 1 F001 1
" D350 IEC 61850 GGIO2.CF.SPCSO49.ctlModel
Value
0 to 2 --- 1 F001 1
" D351 IEC 61850 GGIO2.CF.SPCSO50.ctlModel
Value
0 to 2 --- 1 F001 1
" D352 IEC 61850 GGIO2.CF.SPCSO51.ctlModel
Value
0 to 2 --- 1 F001 1
" D353 IEC 61850 GGIO2.CF.SPCSO52.ctlModel
Value
0 to 2 --- 1 F001 1
" D354 IEC 61850 GGIO2.CF.SPCSO53.ctlModel
Value
0 to 2 --- 1 F001 1
" D355 IEC 61850 GGIO2.CF.SPCSO54.ctlModel
Value
0 to 2 --- 1 F001 1
" D356 IEC 61850 GGIO2.CF.SPCSO55.ctlModel
Value
0 to 2 --- 1 F001 1
" D357 IEC 61850 GGIO2.CF.SPCSO56.ctlModel
Value
0 to 2 --- 1 F001 1
" D358 IEC 61850 GGIO2.CF.SPCSO57.ctlModel
Value
0 to 2 --- 1 F001 1
" D359 IEC 61850 GGIO2.CF.SPCSO58.ctlModel
Value
0 to 2 --- 1 F001 1
" D35A IEC 61850 GGIO2.CF.SPCSO59.ctlModel
Value
0 to 2 --- 1 F001 1
" D35B IEC 61850 GGIO2.CF.SPCSO60.ctlModel
Value
0 to 2 --- 1 F001 1
" D35C IEC 61850 GGIO2.CF.SPCSO61.ctlModel
Value
0 to 2 --- 1 F001 1
" D35D IEC 61850 GGIO2.CF.SPCSO62.ctlModel
Value
0 to 2 --- 1 F001 1
" D35E IEC 61850 GGIO2.CF.SPCSO63.ctlModel
Value
0 to 2 --- 1 F001 1
" D35F IEC 61850 GGIO2.CF.SPCSO64.ctlModel
Value
0 to 2 --- 1 F001 1
Synchrocheck (Read/Write Setting) (4, 6, or 10 Modules)
C60, D30, D60,
F60, G30, G60,
L30, L60, L90,
N60, T60
D430 Synchrocheck 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" D431 Synchrocheck 1 V1 Source 0 to 5 --- 1 F167 0 (SRC 1)
" D432 Synchrocheck 1 V2 Source 0 to 5 --- 1 F167 1 (SRC 2)
" D433 Synchrocheck 1 Maximum Voltage
Difference
0 to 400000 V 1 F060 10000
" D435 Synchrocheck 1 Maximum Angle
Difference
0 to 100 degrees 1 F001 30
" D436 Synchrocheck 1 Maximum Frequency
Difference
0 to 2 Hz 0.01 F001 100
" D437 Synchrocheck 1 Maximum Frequency
Hysteresis
0 to 0.1 Hz 0.01 F001 6
" D438 Synchrocheck 1 Sync Close 0 to 4294967295 --- 1 F300 0
" D43A Synchrocheck 1 S-CLS Maximum dF 0.1 to 2 Hz 0.01 F001 50
" D43B Synchrocheck 1 S-CLS Minimum dF 0.01 to 1 Hz 0.01 F001 10
" D43C Synchrocheck 1 S-CLS Brk Time 0.01 to 0.5 s 0.001 F001 35
Products Address Register name Range Units Step Format Default
