2-216 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
F648
ENUMERATION: GRAPHICAL FRONT PANEL DATE FORMAT
F649
ENUMERATION: GRAPHICAL FRONT PANEL TIME FORMAT
F650
ENUMERATION: GRAPHICAL FRONT PANEL SCREEN SAVER
INTENSITY
F651
ENUMERATION: GRAPHICAL FRONT PANEL LED COLOR
0 = ORANGE, 1 = RED, 2 = GREEN
F652
ENUMERATION: GRAPHICAL FRONT PANEL MISC STATES BIT
POSITIONS
F660
ENUMERATION: DNP SCALE
0 = 0.01, 1 = 0.1, 2 = 1, 3 = 10, 4 = 100, 5 = 1000, 6 = 10000,
7 = 100000, 8 = 0.001, 9 = 1000000, 10 = 10000000, 11 =
100000000
Enumeration Item
0 yyyy-mm-dd
1 dd-mmm-yy
2 yyyy/mm/dd
3 m/d/yyyy
4 m/d/yy
5mm/dd/yy
6 mm/dd/yyyy
7yy/mm/dd
Enumeration Item
0hh:mm:ss
1 h:mm:ss tt
Enumeration Item
00 %
110 %
220 %
330 %
Enumeration Item
0Clock Sync
1 Any Minor Self Test
2 Any Major Self Test
4Operator Active Bit
5Engineer Active Bit
6 Supervisor Active Bit
7 Administrator Active Bit
12 Modbus Security Count Bit 0
13 Modbus Security Count Bit 1
14 Modbus Security Count Bit 2
15 Modbus Security Count Bit 3
Enumeration Item
