3-38 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
3.5.2.2 Accidental energization (AcdEnr)
This element is instantiated in the following products: G30, G60.
Table 3-20: Accidental energization data objects
3.5.2.3 Auxiliary overvoltage (AuxOv)
This element is instantiated in the following products: B30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90, M60, T60.
Table 3-21: Auxiliary overvoltage data objects
3.5.2.4 Auxiliary undervoltage (AuxUv)
This element is instantiated in the following products: C60, D30, D60, F35, F60, G30, G60, L30, L60, L90, M60, T60.
Table 3-22: Auxiliary undervoltage data objects
<TTΣDataS
et##>
DATA-SET R
DSMemberRef[η] ObjectReference DataSet Member η R/C
LNName: AcdEnrPIOC1 LDevice inst: Prot UR element: Accidental Energization element – Over-current function
data obj. data attribute Type FC UR Name Description R/W/C
Op ACT ACCDNT ENRG OP operand R
general BOOLEAN ST ACCDNT ENRG OP R
Dpo SPS ACCDNT ENRG DPO operand R
stVal BOOLEAN ST ACCDNT ENRG DPO R
Armed SPS ACCDNT ENRG ARMED operand R
stVal BOOLEAN ST ACCDNT ENRG ARMED R
InRefγ ORG ACCDNT ENRG OFFLINE setting for
setting group γ.
R
setSrcRef ObjectReference SP ACCDNT ENRG OFFLINE reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
BlkRefγ ORG ACCDNT ENRG BLOCK setting for setting
group γ.
R
setSrcRef ObjectReference SP ACCDNT ENRG BLOCK reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: AuxOvPTOV# LDevice inst: Prot UR element: Auxiliary Overvoltage element # functions
data obj. data attribute Type FC UR Name Description R/W/C
Str ACD AUX OV# PKP operands (including
individual three phases)
R
general BOOLEAN ST AUX OV# PKP R
dirGeneral ENUMERATED ST 0, the code for unknown. It is unknown as
the element is non-directional
R
Op ACT AUX OV# OP operand R
general BOOLEAN ST AUX OV# OP R
Dpo SPS AUX OV# DPO operand, which is the
inverse of AUX OV PKP
R
stVal BOOLEAN ST AUX OV# DPO R
BlkRefγ ORG AUX OV# BLK setting for setting group γ.R
setSrcRef ObjectReference SP AUX OV# BLK for group γ. reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: AuxUvPTUV# LDevice inst: Prot UR element: Auxiliary Undervoltage element# functions
data obj. data attribute Type FC UR Name Description R/W/C
Str ACD AUX UV# PKP operands R
general BOOLEAN ST AUX UV# PKP R
dirGeneral ENUMERATED ST 0, the code for unknown. It is unknown as
the element is non-directional
R
LNName: LLN0 LDevice inst: Prot UR element: Nameplate information for the logical nodes
data obj. data attribute Type FC UR Name Description R/W/C
