GE b30 Communications Manual

CHAPTER 3: IEC 61850 COMMUNICATION MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-39
3
3.5.2.5 B90 breaker failure (B_BFai)
This element is instantiated in the following products: B90.
Table 3-23: B90 breaker failure current data objects
Table 3-24: B90 breaker failure logic data objects
Op ACT AUX UV# OP operand R
general BOOLEAN ST AUX UV# OP R
Dpo SPS AUX UV# DPO operand, which is the
inverse of AUX UV PKP
R
stVal BOOLEAN ST AUX UV# DPO R
BlkRefγ ORG AUX UV# BLOCK setting for setting group
γ.
R
setSrcRef ObjectReference SP AUX UV# BLOCK for group γ. reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: B_BFaiPIOC# LDevice inst: Prot UR element: B90 BREAKER FAILURE CURRENT SUPV # function
data obj. data attribute Type FC UR Name Description R/W/C
Op ACT BKRSUPV # SUPV OP operand R
general BOOLEAN ST BKRSUPV # SUPV OP R
OpHiSet ACT BKRSUPV # HISET OP operand R
general BOOLEAN ST BKRSUPV # HISET OP R
OpLoSet ACT BKRSUPV # LOSET OP operand R
general BOOLEAN ST BKRSUPV # LOSET OP R
LNName: B_BFaiRBRF# LDevice inst: Prot UR element: B90 BREAKER FAILURE logic element
data obj. data attribute Type FC UR Name Description R/W/C
OpEx ACT BKRFAIL # TRIP OP operand R
general BOOLEAN ST BKRFAIL # TRIP OP R
OpIn ACT BKRFAIL # RETRIP operand R
general BOOLEAN ST re-trip operand BKRFAIL #
RETRIP
R
BkrOp& SPS BKRFAIL # T& OP operand R
stVal BOOLEAN ST BKRFAIL # T& OP R
InRefγ01 ORG BF# INITIATE setting for setting group γ.R
setSrcRef ObjectReference SP BF# INITIATE for group γ. reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRefγ02 ORG BF# AMP SUPV OP A setting for setting
group γ.
R
setSrcRef ObjectReference SP BF# AMP SUPV OP A for group γ.reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRefγ03 ORG BF# AMP SUPV OP B setting for setting
group γ.
R
setSrcRef ObjectReference SP BF# AMP SUPV OP B for group γ.reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRefγ04 ORG BF# AMP SUPV OP C setting for setting
group γ.
R
setSrcRef ObjectReference SP BF# AMP SUPV OP C for group γ.reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRefγ05 ORG BF# BKR POS1 setting for setting group γ.R
setSrcRef ObjectReference SP BF# BKR POS1 for group γ. reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRefγ06 ORG BF# BKR POS2 setting for setting group γ.R
setSrcRef ObjectReference SP BF# BKR POS2 for group γ. reference to the data attribute to input R/C
LNName: AuxUvPTUV# LDevice inst: Prot UR element: Auxiliary Undervoltage element# functions
data obj. data attribute Type FC UR Name Description R/W/C
