CHAPTER 3: IEC 61850 COMMUNICATION MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-109
3
3.5.2.78 Undercurrent (UnCur)
This element is instantiated in the following products: M60.
stVal BOOLEAN ST TRIP AR INIT 3-POLE R
Tr3pFrcd SPS TRIP FORCE 3-POLE operand (3-pole trip
mode is being forced)
R
stVal BOOLEAN ST TRIP FORCE 3-POLE R
StrZ2PhDl SPS TRIP Z2PH TMR INIT operand R
stVal BOOLEAN ST TRIP Z2PH TMR INIT R
StrZ2GndDl SPS TRIP Z2GR TMR INIT operand R
stVal BOOLEAN ST TRIP Z2GR TMR INIT R
InRef3α ORG TRIP 3-POLE INPUT-α setting. R
setSrcRef ObjectReference SP TRIP 3-POLE INPUT-α setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef1α ORG TRIP 1-POLE INPUT-α setting. R
setSrcRef ObjectReference SP TRIP 1-POLE INPUT-α setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef2α ORG TRIP RECLOSE INPUT-α setting. R
setSrcRef ObjectReference SP TRIP RECLOSE INPUT-α setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef01 ORG START TMR Z2PH Inp1 setting. R
setSrcRef ObjectReference SP START TMR Z2PH Inp1 setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef02 ORG START TMR Z2PH Inp2 setting. R
setSrcRef ObjectReference SP START TMR Z2PH Inp2 setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef03 ORG START TMR Z2GR Inp1 setting. R
setSrcRef ObjectReference SP START TMR Z2GR Inp1 setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef04 ORG START TMR Z2GR Inp2 setting. R
setSrcRef ObjectReference SP START TMR Z2GR Inp2 setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef05 ORG BKR φA OPEN setting. R
setSrcRef ObjectReference SP BKR φA OPEN setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef06 ORG BKR φB OPEN setting. R
setSrcRef ObjectReference SP BKR φB OPEN setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef07 ORG BKR φC OPEN setting. R
setSrcRef ObjectReference SP BKR φC OPEN setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef08 ORG TRIP FORCE 3-POLE setting. R
setSrcRef ObjectReference SP TRIP FORCE 3-POLE setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef09 ORG REVERSE FAULT setting. R
setSrcRef ObjectReference SP REVERSE FAULT setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: TrOutPTRC1 LDevice inst: Prot UR element: Trip Output element
data obj. data attribute Type FC UR Name Description R/W/C
