3.5.4.14 Latched outputs (FLOut)
This element is instantiated in all UR products (B30, B90, C30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90, M60,
N60, T35, T60).
Table 3-188: Latched output data objects
3.5.4.15 Shared inputs (FShIn)
This element is instantiated in all UR products (B30, B90, C30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90, M60,
N60, T35, T60).
Table 3-189: Shared input data objects
3.5.4.16 Shared outputs (FShOut)
This element is instantiated in all UR products (B30, B90, C30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90, M60,
N60, T35, T60).
Table 3-190: Shared output data objects
3.5.4.17 Transducer DCmA inputs (TDCIn)
This element is instantiated in the following products: B30, C30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90, M60,
N60, T35, T60.
stepSize.f FLOAT32 0.001 R
LNName: FLOutGGIO1 LDevice inst: System UR element: Field Latching Outputs
data obj. data attribute Type FC UR Name Description R/W/C
Ind1Θ SPS FLO Θ Opened operand value R
stVal BOOLEAN ST FLO Θ Opened R
Ind2Θ SPS FLO Θ Closed operand value R
stVal BOOLEAN ST FLO Θ Closed R
Ind3Θ SPS FLO Θ OpnDOn operand value R
stVal BOOLEAN ST FLO Θ OpnDOn R
Ind4Θ SPS FLO Θ ClsDOn operand value R
stVal BOOLEAN ST FLO Θ ClsDOn R
InRef1Θ ORG FLO Θ Open setting. R
setSrcRef ObjectReference SP Open setting of FLO Θ reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef2Θ ORG FLO Θ Close setting. R
setSrcRef ObjectReference SP Close setting of FLO Θ reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: FShInGGIO1 LDevice inst: System UR element: Field Shared Inputs
data obj. data attribute Type FC UR Name Description R/W/C
IndΘ SPS SI Θ On operand value R
stVal BOOLEAN ST SI Θ On R
LNName: FShOutGGIO1 LDevice inst: System UR element: Field Shared Outputs
data obj. data attribute Type FC UR Name Description R/W/C
InRefΘ ORG SOΘ Operate setting. R
setSrcRef ObjectReference SP Operate setting of SOΘ reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: FTDRsGGIO1 LDevice inst: System UR element: Field Transducers
data obj. data attribute Type FC UR Name Description R/W/C
