3-184 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
3.5.5.5 Energy metering (EnrMtr)
This element is instantiated in the following products: C60, D60, F35, F60, G30, G60, L90, M60, N60, T60.
Table 3-202: Energy metering data objects
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 63 is unit for apparent power in volt-
ampere
R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF DmdMtrMMTR#.VArDmd.db R/W/C
zeroDb INT32U CF power cut-off level. R
VArMaxDm
dDt
MV SRC # DMD VAR, in primary volt ampere
reactive, with associated date, SRC #
DMD VAR DATE
R
mag AnalogueValue MX R
mag.f FLOAT32 SRC # DMD VAR MAX R
units Unit CF R
units.SIUnit ENUMERATED 63 is unit for apparent power in volt-
ampere
R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
VADmd MV SRC # DMD VA, in primary volt ampere R
instMag AnalogueValue MX R
instMag.f FLOAT32 SRC # DMD VA R
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 61 is unit for apparent power in volt-
ampere
R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF DmdMtrMMTR#.VADmd.db R/W/C
zeroDb INT32U CF power cut-off level. R
VAMaxDm
dDt
MV SRC # DMD VA, in primary volt ampere,
with associated date, SRC # DMD VA
DATE
R
mag AnalogueValue MX R
mag.f FLOAT32 SRC # DMD VA MAX R
units Unit CF R
units.SIUnit ENUMERATED 61 is unit for apparent power in volt-
ampere
R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
LNName: EnrMtrMMTR# LDevice inst: Meter UR element: Signal Source # Energy Metering
data obj. data attribute Type FC UR Name Description R/W/C
PosTotWh MV SRC # Total Watt-hour in positive
direction
R
instMag AnalogueValue MX R
instMag.f FLOAT32 SRC # POS WATTHOUR R
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 72, the code for real energy in watt hours
(Wh)
R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF EnrMtrMMTR#.PosTotWh.db R/W/C
LNName: DmdMtrMMTR# LDevice inst: Meter UR element: Signal Source # NAME Demand Metering
data obj. data attribute Type FC UR Name Description R/W/C
