CHAPTER 3: IEC 61850 COMMUNICATION MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS)
UR FAMILY – COMMUNICATIONS GUIDE 3-183
3
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 5, the code for primary amperes R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF DmdMtrMMTR#.AbDmd.db R/W/C
zeroDb INT32U CF current cut-off level. R
AbMaxDm
dDt
MV SRC # DMD IB MAX, in primary amperes
with associated date, SRC # DMD IB DATE
R
mag AnalogueValue MX R
mag.f FLOAT32 SRC # DMD IB MAX R
units Unit CF R
units.SIUnit ENUMERATED 5, the code for primary amperes R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
AcDmd MV SRC # DMD IC, in primary amperes R
instMag AnalogueValue MX R
instMag.f FLOAT32 SRC # DMD IC R
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 5, the code for primary amperes R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF DmdMtrMMTR#.AcDmd.db R/W/C
zeroDb INT32U CF current cut-off level. R
AcMaxDm
dDt
MV SRC # DMD IC MAX, in primary amperes
with associated date, SRC # DMD IC DATE
R
mag AnalogueValue MX R
mag.f FLOAT32 SRC # DMD IC MAX R
units Unit CF R
units.SIUnit ENUMERATED 5, the code for primary amperes R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
WDmd MV SRC # DMD W, in primary watt R
instMag AnalogueValue MX R
instMag.f FLOAT32 SRC # DMD W R
mag AnalogueValue MX R
mag.f FLOAT32 instMag.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 38 is unit for power in watts R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF DmdMtrMMTR#.WDmd.db R/W/C
zeroDb INT32U CF power cut-off level. R
WMaxDmd
Dt
MV SRC # DMD W, in primary watt, with
associated date, SRC # DMD W DATE
R
mag AnalogueValue MX R
mag.f FLOAT32 SRC # DMD W MAX R
units Unit CF R
units.SIUnit ENUMERATED 38 is unit for power in watts R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
VArDmd MV SRC # DMD VAR, in primary volt ampere
reactive
R
instMag AnalogueValue MX R
instMag.f FLOAT32 SRC # DMD VAR R
LNName: DmdMtrMMTR# LDevice inst: Meter UR element: Signal Source # NAME Demand Metering
data obj. data attribute Type FC UR Name Description R/W/C
