3-192 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
3.5.6.6 Data logger (DatLog)
This element is instantiated in the following products: B30, C30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90, M60,
N60, T35, T60.
Table 3-209: Data logger data objects
instCVal.ang.f FLOAT32 Local Vcomp Ang R
cVal Vector MX R
cVal.mag.f FLOAT32 instCVal.mag.f deadbanded R
cVal.ang.f FLOAT32 instCVal.ang.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 29, the code for primary volts R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF VCompMMXU1.VolLoc.db R/W/C
dbAng INT32U CF VCompMMXU1.VolLoc.dbAng R/W/C
zeroDb INT32U CF 0 R
VolRem1 CMV Term 1 Vcomp phasor, in primary volts R
instCVal Vector MX R
instCVal.mag.f FLOAT32 Term 1 Vcomp Mag R
instCVal.ang.f FLOAT32 Term 1 Vcomp Ang R
cVal Vector MX R
cVal.mag.f FLOAT32 instCVal.mag.f deadbanded R
cVal.ang.f FLOAT32 instCVal.ang.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 29, the code for primary volts R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF VCompMMXU1.VolRem1.db R/W/C
dbAng INT32U CF VCompMMXU1.VolRem1.dbAng R/W/C
zeroDb INT32U CF 0 R
VolRem2 CMV Term 2 Vcomp phasor, in primary volts R
instCVal Vector MX R
instCVal.mag.f FLOAT32 Term 2 Vcomp Mag R
instCVal.ang.f FLOAT32 Term 2 Vcomp Ang R
cVal Vector MX R
cVal.mag.f FLOAT32 instCVal.mag.f deadbanded R
cVal.ang.f FLOAT32 instCVal.ang.f deadbanded R
units Unit CF R
units.SIUnit ENUMERATED 29, the code for primary volts R
units.multiplier ENUMERATED 0, the code for a multiplier of 1 R
db INT32U CF VCompMMXU1.VolRem2.db R/W/C
dbAng INT32U CF VCompMMXU1.VolRem2.dbAng R/W/C
zeroDb INT32U CF 0 R
LNName: DatLogRDRE1 LDevice inst: Gen UR element: Data Logger
data obj. data attribute Type FC UR Name Description R/W/C
FltNum INS Fault number R
stVal INT32 ST 0 if data logger is cleared, 1 once a
sample has been recorded.
R
RcdMade SPS Recording started, timestamp mapped to
NEWEST SAMPLE TIME actual
R
LNName: VCompMMXU1 LDevice inst: Gen UR element: Current Differential Composite Voltage element
data obj. data attribute Type FC UR Name Description R/W/C
