3-200 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
3.5.6.16 Target resetting (TgtRs)
This element is instantiated in all UR products (B30, B90, C30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90, M60,
N60, T35, T60).
Table 3-219: Target resetting data objects
3.5.6.17 Time of day timer (TmDay)
This element is instantiated in the following products: C70.
Table 3-220: Time of day timer data objects
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef5 ORG SELECTOR # 3BIT A2 setting. R
setSrcRef ObjectReference SP SELECTOR # 3BIT A2 setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef6 ORG SELECTOR # 3BIT ACK setting. R
setSrcRef ObjectReference SP SELECTOR #3BIT ACK setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: TgtRsIHMI1 LDevice inst: Gen UR element: Target Resetting
data obj. data attribute Type FC UR Name Description R/W/C
Mod INC This logical node’s mode R/Ctrl
stVal ENUMERATED ST 1 (on) R
ctlModel CtlModels CF 0 (status only) R
Health INS This logical node’s health R
stVal ENUMERATED ST LPHD1.PhyHealth.stVal R
RsOp SPS RESET OP operand value R
stVal BOOLEAN ST RESET OP R
RsOpRem SPS RESET OP (COMMS) operand value R
stVal BOOLEAN ST RESET OP (COMMS) R
RsOpLoc SPS RESET OP (OPERAND) operand value R
stVal BOOLEAN ST RESET OP (OPERAND) R
RsOpPB SPS RESET OP (PUSHBUTTON) operand value R
stVal BOOLEAN ST RESET OP (PUSHBUTTON) R
InRef1 ORG RESET OPERAND setting. R
GEORG R
setSrcRef ObjectReference SP RESET OPERAND reference to the data attribute to input R/C
VISIBLE
STRING255
SP Reference to the ultimate source
of value selected by setting
RESET OPERAND
R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
VISIBLE
STRING255
SP If reference is external to this
IED, mapped to the source’s
GOOSE control block, else empty
string
R/C
cdcNs VISIBLE
STRING255
EX Name of the GE Multilin
namespace at the time of this
firmware release
R
cdcName VISIBLE
STRING255
EX GEORG R
LNName: TmDayGAPC# LDevice inst: Gen UR element: TIME OF DAY TIMER #
data obj. data attribute Type FC UR Name Description R/W/C
Mod INC This logical node’s mode R/Ctrl
stVal ENUMERATED ST 1 (on) R
ctlModel CtlModels CF 0 (status only) R
LNName: SelSwGAPC# LDevice inst: Gen UR element: Selector Switch element #
data obj. data attribute Type FC UR Name Description R/W/C
