MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
Table 3-222: User-programmable pushbutton data objects
3.5.6.20 User-programmable LEDs (LEDs)
This element is instantiated in the following products: B30, B90, C30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90,
M60, N60, T35, T60.
Table 3-223: User-programmable LED data objects
LNName: UsrPbIHMI# LDevice inst: Gen UR element: USER PUSHBUTTON # function
data obj. data attribute Type FC UR Name Description R/W/C
PBOn SPS PUSHBUTTON # ON operand. R
stVal BOOLEAN ST PUSHBUTTON # ON R
Deactivate
d
SPS PUSHBUTTON # OFF operand. R
stVal BOOLEAN ST PUSHBUTTON # OFF R
AnyPBOn SPS Instantiated only in first Instance R
stVal BOOLEAN ST ANY PB ON R
InRef1 ORG PUSHBTN # SET setting. R
setSrcRef ObjectReference SP PUSHBTN # SET setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef2 ORG PUSHBTN # RESET setting. R
setSrcRef ObjectReference SP PUSHBTN # RESET setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef3 ORG PUSHBTN # REMOTE setting. R
setSrcRef ObjectReference SP PUSHBTN # REMOTE setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef4 ORG PUSHBTN # LOCAL setting. R
setSrcRef ObjectReference SP PUSHBTN # LOCAL setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef5 ORG PUSHBTN # LED CTL setting. R
setSrcRef ObjectReference SP PUSHBTN # LED CTL setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: LEDsIHMI1 LDevice inst: Gen UR element: Front Panel LEDs
data obj. data attribute Type FC UR Name Description R/W/C
InService SPS LED IN SERVICE operand R
stVal BOOLEAN ST LED IN SERVICE R
Trouble SPS LED TROUBLE operand R
stVal BOOLEAN ST LED TROUBLE R
TestMod SPS LED TEST MODE operand R
stVal BOOLEAN ST LED TEST MODE R
TripInd SPS LED TRIP operand R
stVal BOOLEAN ST LED TRIP R
AlmInd SPS LED ALARM operand R
stVal BOOLEAN ST LED ALARM R
StrInd SPS LED PICKUP operand R
stVal BOOLEAN ST LED PICKUP R
VoltsInd SPS LED VOLTAGE operand R
stVal BOOLEAN ST LED VOLTAGE R
AmpInd SPS LED CURRENT operand R
stVal BOOLEAN ST LED CURRENT R
HzLedInd SPS LED FREQUENCY operand R
stVal BOOLEAN ST LED FREQUENCY R
OtherInd SPS LED OTHER operand R
