CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-77
2
" 5F53 Frequency Out-Of-Band Accumulator
Target Messages Enable
0 to 2 --- 1 F109 0 (Self-reset)
" 5F54 Frequency Out-Of-Band Accumulator Time
Limit Array (7 items)
1 to 65535 sec 1 F001 200
" 5F5B Frequency Out-Of-Band Accumulator Time
Preset Array (7 items)
0 to 65535 sec 1 F001 0
" 5F62 Frequency Out-Of-Band Accumulator
Upper Frequency Array (7 items)
20 to 70 Hz 0.01 F001 6000
Setting Groups (Read/Write Setting)
All except C30 5F70 Setting Group for Modbus Comms (0
means group 1)
0 to 5 --- 1 F001 0
" 5F71 Setting Groups Block 0 to 4294967295 --- 1 F300 0
" 5F73 FlexLogic Operands to Activate Groups 2
through 6 (5 items)
0 to 4294967295 --- 1 F300 0
" 5F7D Setting Group Function 0 to 1 --- 1 F102 0 (Disabled)
" 5F7E Setting Group Events 0 to 1 --- 1 F102 0 (Disabled)
Setting Groups (Read Only)
All except C30 5F7F Current Setting Group 0 to 5 --- 1 F001 0
Setting Group Names (Read/Write Setting)
All except C30 5F8C Setting Group 1 Name --- --- --- F203 (none)
" 5F94 Setting Group 2 Name --- --- --- F203 (none)
" 5F9C Setting Group 3 Name --- --- --- F203 (none)
" 5FA4 Setting Group 4 Name --- --- --- F203 (none)
" 5FAC Setting Group 5 Name --- --- --- F203 (none)
" 5FB4 Setting Group 6 Name --- --- --- F203 (none)
Current Differential 87L (Read/Write Grouped Setting)
L30, L90 6000 87L Current Differential Function 0 to 1 --- 1 F102 0 (Disabled)
" 6001 87L Current Differential Block 0 to 4294967295 --- 1 F300 0
" 6003 87L Current Differential Signal Source 1 0 to 5 --- 1 F167 0 (SRC 1)
" 6004 87L Minimum Phase Current Sensitivity 0.1 to 4 pu 0.01 F001 20
" 6005 87L Current Differential Tap Setting 0.2 to 5 --- 0.01 F001 100
" 6006 87L Current Differential Phase Percent
Restraint 1
1 to 50 % 1 F001 30
" 6007 87L Current Differential Phase Percent
Restraint 2
1 to 70 % 1 F001 50
" 6008 87L Current Differential Phase Dual Slope
Breakpoint
0 to 20 pu 0.1 F001 10
" 6009 87L Current Differential Ground Function 0 to 1 --- 1 F102 0 (Disabled)
" 600A 87L Current Differential Ground Pickup 0.05 to 1 pu 0.01 F001 10
" 600B 87L Current Differential Ground Restraint 1 to 50 % 1 F001 25
" 600C 87L Current Differential Ground Delay 0 to 5 seconds 0.01 F001 10
" 600D 87L Current Differential Key DTT 0 to 1 --- 1 F102 1 (Enabled)
" 600E 87L Current Differential External Key DTT 0 to 4294967295 --- 1 F300 0
" 6010 87L Current Differential Target 0 to 2 --- 1 F109 0 (Self-reset)
" 6011 87L Current Differential Event 0 to 1 --- 1 F102 0 (Disabled)
" 6012 87L Current Differential Tap 2 Setting 0.2 to 5 --- 0.01 F001 100
L90 6013 87L Current Differential Signal Source 2 0 to 6 --- 1 F211 0 (None)
" 6014 87L Current Differential Signal Source 3 0 to 6 --- 1 F211 0 (None)
" 6015 87L Current Differential Signal Source 4 0 to 6 --- 1 F211 0 (None)
Products Address Register name Range Units Step Format Default
