2-76 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
F35 5EC6 ...Repeated for Incipient Cable Fault
Detector 3
" 5EC9 ...Repeated for Incipient Cable Fault
Detector 4
" 5ECC ...Repeated for Incipient Cable Fault
Detector 5
" 5ECF ...Repeated for Incipient Cable Fault
Detector 6
Incipient Cable Fault Detector Command (Read/Write Setting)
D30, F35, F60,
L30
5ED8 Incipient Cable Fault Detector Clear
Counters
0 to 1 --- 1 F126 0 (No)
87L Trip Logic (Read/Write Grouped Setting)
L90 5EE0 87L Trip Function 0 to 1 --- 1 F102 0 (Disabled)
" 5EE1 87L Trip Source 0 to 5 --- 1 F167 0 (SRC 1)
" 5EE2 87L Trip Mode 0 to 1 --- 1 F157 0 (3-Pole)
" 5EE3 87L Trip Supervision 0 to 4294967295 --- 1 F300 0
" 5EE5 87L Trip Force 3 Phase 0 to 4294967295 --- 1 F300 0
" 5EE7 87L Trip Seal In 0 to 1 --- 1 F102 0 (Disabled)
" 5EE8 87L Trip Seal In Pickup 0.2 to 0.8 pu 0.01 F001 20
" 5EE9 87L Trip Target 0 to 2 --- 1 F109 0 (Self-reset)
" 5EEA 87L Trip Events 0 to 1 --- 1 F102 0 (Disabled)
" 5EEB 87LG Trip Mode 0 to 1 --- 1 F157 0 (3-Pole)
" 5EEC 87LG Trip Supervision 0 to 4294967295 --- 1 F300 0
Stub Bus (Read/Write Grouped Setting)
L30, L90 5F10 Stub Bus Function 0 to 1 --- 1 F102 0 (Disabled)
" 5F11 Stub Bus Disconnect 0 to 4294967295 --- 1 F300 0
" 5F13 Stub Bus Trigger 0 to 4294967295 --- 1 F300 0
" 5F15 Stub Bus Target 0 to 2 --- 1 F109 0 (Self-reset)
" 5F17 Stub Bus Events 0 to 1 --- 1 F102 0 (Disabled)
50DD Disturbance Detection (Read/Write Grouped Setting)
L30, L90 5F20 50DD Function 0 to 1 --- 1 F102 0 (Disabled)
" 5F21 50DD Non Current Supervision 0 to 4294967295 --- 1 F300 0
" 5F23 50DD Control Logic 0 to 4294967295 --- 1 F300 0
" 5F25 50DD Logic Seal In 0 to 4294967295 --- 1 F300 0
" 5F27 50DD Events 0 to 1 --- 1 F102 0 (Disabled)
" 5F28 50DD Seal-In by 87LG 0 to 1 --- 1 F102 0 (Disabled)
" 5F29 50DD Voltage Supv 0 to 1 --- 1 F102 0 (Disabled)
Frequency Out-Of-Band Accumulation (Read/Write Setting)
G30, G60 5F40 Frequency Out-Of-Band Accumulation
Block
0 to 4294967295 --- 1 F300 0
" 5F42 Frequency Out-Of-Band Accumulation
Events Enable
0 to 1 --- 1 F102 0 (Disabled)
" 5F43 Frequency Out-Of-Band Accumulator
Function Enable Array (7 items)
0 to 1 --- 1 F102 0 (Disabled)
" 5F4A Frequency Out-Of-Band Accumulator
Lower Frequency Array (7 items)
20 to 70 Hz 0.01 F001 6000
" 5F51 Frequency Out-Of-Band Accumulator Min
Value V A
0.1 to 1.25 pu 0.01 F001 10
" 5F52 Frequency Out-Of-Band Accumulator
Source
0 to 5 --- 1 F167 0 (SRC 1)
Products Address Register name Range Units Step Format Default
