6
Door ice bin*
1. Open left fresh food door.
2. Pull down latch to release bin
door.
3. Using handhold lift ice bucket up
and out to clear locators in bot-
tom of bin.
4. To replace the ice bucket, set
it on the guide brackets and
push until the ice bucket seats
properly.
5. If bucket cannot be replaced,
rotate the Ice Bucket Fork 1/4
turn clockwise.
Drop down dairy bin*
1. Open right fresh food door.
2. Depress both buttons on lower
sides and bin will drop down.
3. Reverse to reinstall.
Ice/water filter
Remove filter/bypass plug
Push the indent on the cover and
open filter door. Pull out on filter/
bypass plug and pull straight back
to remove.
Installing the filter cartridge
Push the indent at the bottom of
the cover and open. Lift door and
align tabs on filter to filter/holder
and push filter into place.
Drop tray
(tray open)
Push in and
pull open
Ice bucket
Latch
About the features .
*Select Models Only
Swing
Push \ Pull
1
2
