GE Café series Installation Instructions

Installation Instructions
INSTALLING THE REFRIGERATOR (cont.)
26
REMOVE THE FREEZER DOOR
Pull the freezer door open to full extension.
Remove 3 attachment screws, located at the bottom
on each side of the freezer door using 3/8” hex socket
driver.
CAUTION
Lifting Hazard
Freezer door is heavy Use both hands to secure the
door before lifting.
Lift the freezer door to disengage it from the slide
mechanism
The door can safely rest on the bottom. Do not rest the
door on any other surfaces to avoid scratches.
Push the slide mechanism back completely until it self
retracts.
A
B
C
6
REPLACING THE FREEZER DOOR
Pull the slide Mechanism to full extension using both
hands simultaneously.
Remove the basket resting on the slides.
CAUTION
Lifting Hazard
Freezer door is heavy Use both hands to secure the
door before lifting.
Lift the freezer door and place it on the slide mechanism
Replace the attachment screws and torque the screws
to 65 in-lb
For adjusting freezer door gaps, follow the instructions
on pg 27.
Replace the basket
A
B
C
D
7
E
F
Align and insert
tab on freezer
door bracket
into slot on
freezer slide
bracket.

GE Café series Specifications

General

Brand	GE
Category	Refrigerator
Capacity	Varies by model
Ice Maker	Yes
Height	Varies by model
Width	Varies by model
Depth	Varies by model
Total Capacity	Varies by model
Refrigerator Capacity	Varies by model
Freezer Capacity	Varies by model
Adjustable Shelves	Yes
Finish	Stainless Steel
Energy Star Certified	Yes
Water Dispenser	Yes
Smart Capabilities	Yes
Counter Depth	Yes
Door Style	French door
Water Dispenser Type	Internal
Door Alarm	Yes
Color Options	Stainless Steel, Matte White, Matte Black
Series	Café
Style	French Door
Configuration	French Door
