Hot Water Tank and Water Valve
Water Inlet Tube
from valve to hot water tank
Hot Water
Outlet Tube
Hot Water
Thermistors
Hot Water Tank
Filled Switch
750 Watt Hot Water Tank Heater
305˚ internal TCOs
Water Valve Flow Meter
Door Board
Even though the TCOs are rated at 305 F˚ they will trip very quickly
if the heater is not complete submersed in water because they are
located inside the Calrod heater where shown above.
NOTE: The hot water tank will only be stocked
as a complete assembly for service.
